| Model | YT-1P1S |
| Filter bag# | 2# |
| Filter bag Qty | 1 |
| Firltration area(m²) | 0.25 |
| Connection | DN50 |
| Max. Flow (m³/h) | 20 |
| Working pressure(MPa) | 0.6 |
Advantages of bag filter:
◆ High capacity, small size
◆ Easy to replace the filter bag, no need clean and labor saving
◆ After cleaning the filter bag can be used repeatedly to save cost
◆ Filter precision reached 0.5-100 μm
◆ Lower leakage risk ensures high quality
◆ High working pressure, low pressure loss, low operation cost and energy saving
◆ Wide application, flexible use, various installation model for choice.
Single-bag filter is a new type of filter equipment, which is designed with reference to steel pressure vessels. It is made of pure stainless steel and manufactured according to strict quality standards. It has good sealing performance, excellent corrosion resistance, exquisite workmanship, and is safe and reliable.
The filter specifications are complete, including low-pressure type, side-entry type, multi-bag type, and horizontal type. It can meet the filtering requirements of different flows. Materials include 304 stainless steel, 316 stainless steel, 316L stainless steel.
Cartridge filter, also known as security filter. The shell is made of high quality stainless steel, filter using molded filter, The liquid went through filter under pressure, residue left on the filter, and the filtrate outflow through the filter can effectively remove impurities in the water, sediment and suspended solids, bacteria. Molded filters are: cloth, screen, filter, sintered filter tube, wound filter, melt-blown filter, micro-porous filter and multi-function filter. Due to different filter, the filter pore size is not the same. Precision filter is between the sand filter (coarse) and a filter between ultra-filtration, filter pore size generally between 0.01-120um.For the same form of filter,it is divided into different models by their dimensions.
